How we could  fix a nasty out of space issue leveraging the flexibility of Percona MySQL operator (PMO)

When planning a database deployment, one of the most challenging factors to consider is the amount of space we need to dedicate for Data on disk.

This is even more cumbersome when working on bare metal. Given it is definitely more difficult to add space when using this kind of solution in respect to the cloud.

This is it, when using cloud storage like EBS or similar it is normally easy(er) to extend volumes, which gives us the luxury to plan the space to allocate for data with a good grade of relaxation.

Is this also true when using a solution based on Kubernetes like Percona Operator for MySQL? Well it depends on where you run it, however if the platform you choose supports the option to extend volumes K8s per se is giving you the possibility to do so as well.

However, if it can go wrong it will, and ending up with a fully filled device with MySQL is not a fun experience.

As you know, on normal deployments, when mysql has no space left on the device, it simply stops working, ergo it will cause a production down event, which of course is an unfortunate event that we want to avoid at any cost.

This blog is the story of what happened, what was supposed to happen and why.

The story

Case was on AWS using EKS.

Given all the above, I was quite surprised when we had a case in which a deployed solution based on PMO went out of space. However we start to dig and review what was going on and why.

The first thing we did was to quickly investigate what was really taking space, that could have been an easy win if most of the space was taken by some log, but unfortunately this was not the case, data was really taking all the available space.

The next step was to check what storage class was used for the PVC

k get pvc
NAME                         VOLUME    CAPACITY   ACCESS MODES   STORAGECLASS
datadir-mt-cluster-1-pxc-0   pvc-<snip>   233Gi      RWO            io1
datadir-mt-cluster-1-pxc-1   pvc-<snip>   233Gi      RWO            io1
datadir-mt-cluster-1-pxc-2   pvc-<snip>   233Gi      RWO            io1

Ok we use the io1 SC, it is now time to check if the SC is supporting volume expansion:

kubectl describe sc io1
Name:            io1
IsDefaultClass:  No
Annotations:     kubectl.kubernetes.io/last-applied-configuration={"apiVersion":"storage.k8s.io/v1","kind":"StorageClass","metadata":{"annotations":{"storageclass.kubernetes.io/is-default-class":"false"},"name":"io1"},"parameters":{"fsType":"ext4","iopsPerGB":"12","type":"io1"},"provisioner":"kubernetes.io/aws-ebs"}
,storageclass.kubernetes.io/is-default-class=false
Provisioner:           kubernetes.io/aws-ebs
Parameters:            fsType=ext4,iopsPerGB=12,type=io1
AllowVolumeExpansion:  <unset> <------------
MountOptions:          <none>
ReclaimPolicy:         Delete
VolumeBindingMode:     Immediate
Events:                <none>

And no is not enabled, in this case we cannot just go and expand the volume, must change the storage class settings first.
To enable volume expansion, you need to delete the storage class and enable it again.

Unfortunately we were unsuccessful in doing that operation, because the storage class kept staying as unset for  ALLOWVOLUMEEXPANSION.

As said this is a production down event, so we cannot invest too much time in digging why it was not correctly changing the mode, we had to act quickly.

The only option we had to fix it was:

• Expand the io1 volumes from AWS console (or aws client)
• Resize the file system
• Patch any K8 file to allow K8 to correctly see the new volumes dimension

Expanding EBS volumes from the console is trivial, just go to Volumes, select the volume you want to modify, choose modify and change the size of it with the one desired, done.

Once that is done connect to the Node hosting the pod which has the volume mounted like:

 k get pods -o wide|grep mysql-0
NAME                                        READY     STATUS    RESTARTS   AGE    IP            NODE
cluster-1-pxc-0                               2/2     Running   1          11d    10.1.76.189     <mynode>.eu-central-1.compute.internal

Then we need to get the id of the pvc to identify it on the node

k get pvc
NAME                         STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS
datadir-cluster-1-pxc-0   Bound    pvc-1678c7ee-3e50-4329-a5d8-25cd188dc0df   233Gi      RWO            io1

One note, when doing this kind of recovery with a PXC based solution, always recover node-0 first, then the others.

So we connect to <mynode> and identify the volume:

lslbk |grep pvc-1678c7ee-3e50-4329-a5d8-25cd188dc0df
nvme1n1      259:4    0  350G  0 disk /var/lib/kubelet/pods/9724a0f6-fb79-4e6b-be8d-b797062bf716/volumes/kubernetes.io~aws-ebs/pvc-1678c7ee-3e50-4329-a5d8-25cd188dc0df <-----

At this point we can resize it:

root@ip-<snip>:/# resize2fs  /dev/nvme1n1
resize2fs 1.45.5 (07-Jan-2020)
Filesystem at /dev/nvme1n1 is mounted on /var/lib/kubelet/plugins/kubernetes.io/aws-ebs/mounts/aws/eu-central-1a/vol-0ab0db8ecf0293b2f; on-line resizing required
old_desc_blocks = 30, new_desc_blocks = 44
The filesystem on /dev/nvme1n1 is now 91750400 (4k) blocks long.

The good thing is that as soon as you do that the MySQL daemon see the space and will restart, however it will happen only on the current pod and K8 will still see the old dimension:

k get pv
NAME                                       CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS   CLAIM                            STORAGECLASS   REASON
pvc-1678c7ee-3e50-4329-a5d8-25cd188dc0df   333Gi      RWO            Delete           Bound    pxc/datadir-cluster-1-pxc-0   io1

To allow k8 to be align with the real dimension we must patch the information stored, the command is the following:

kubectl patch pvc <pvc-name>  -n <pvc-namespace> -p '{ "spec": { "resources": { "requests": { "storage": "NEW STORAGE VALUE" }}}}'
Ie:
kubectl patch pvc datadir-cluster-1-pxc-0 -n pxc -p '{ "spec": { "resources": { "requests": { "storage": "350" }}}}'

Remember to use as pvc-name the NAME coming from

kubectl get pvc.

Once this is done k8 will see the new volume dimension correctly.

Just repeat the process for Node-1 and Node-2 and …done the cluster is up again.

Finally do not forget to modify your custom resources file (cr.yaml) to match the new volume size. IE:

    volumeSpec:
      persistentVolumeClaim:
        storageClassName: "io1"
        resources:
          requests:
            storage: 350G

The whole process took just a few minutes, it was time now to investigate why the incident happened and why the storage class was not allowing extension in the first place.

Why it happened

Well first and foremost the platform was not correctly monitored. As such there was lack of visibility about the space utilization, and no alert about disk space.

This was easy to solve just enabling the PMM feature in the cluster cr and set the alert in PMM once the nodes join it (see https://docs.percona.com/percona-monitoring-and-management/get-started/alerting.html for details on how to).

The second issue was the problem with the storage class. Once we had the time to carefully review the configuration files, we identified that there was an additional tab in the SC class, which was causing k8 to ignore the directive.

Was suppose to be:

kind: StorageClass
apiVersion: storage.k8s.io/v1
metadata:
  name: io1
  annotations:
    storageclass.kubernetes.io/is-default-class: "false"
provisioner: kubernetes.io/aws-ebs
parameters:
  type: io1
  iopsPerGB: "12"
  fsType: ext4
allowVolumeExpansion: true <----------

It was:
kind: StorageClass
apiVersion: storage.k8s.io/v1
metadata:
  name: io1
  annotations:
    storageclass.kubernetes.io/is-default-class: "false"
provisioner: kubernetes.io/aws-ebs
parameters:
  type: io1
  iopsPerGB: "12"
  fsType: ext4
  allowVolumeExpansion: true. <---------

What was concerning was the lack of error returned by the Kubernetes API, so in theory the configuration was accepted but not really validated.

In any case once we had fix the typo and recreated the SC, the setting for volume expansion was correctly accepted:

kubectl describe sc io1
Name:            io1
IsDefaultClass:  No
Annotations:     kubectl.kubernetes.io/last-applied-configuration={"allowVolumeExpansion":true,"apiVersion":"storage.k8s.io/v1","kind":"StorageClass","metadata":{"annotations":{"storageclass.kubernetes.io/is-default-class":"false"},"name":"io1"},"parameters":{"fsType":"ext4","iopsPerGB":"12","type":"io1"},"provisioner":"kubernetes.io/aws-ebs"}
,storageclass.kubernetes.io/is-default-class=false
Provisioner:           kubernetes.io/aws-ebs
Parameters:            fsType=ext4,iopsPerGB=12,type=io1
AllowVolumeExpansion:  True
MountOptions:          <none>
ReclaimPolicy:         Delete
VolumeBindingMode:     Immediate
Events:                <none>

What should have happened instead?

If a proper monitoring and alerting was in place, the administrators would have the time to act and extend the volumes without downtime.

However, the procedure for extending volumes on K8 is not complex but also not as straightforward as you may think. My colleague Natalia Marukovich wrote this blog post (https://www.percona.com/blog/percona-operator-volume-expansion-without-downtime/)  that gives you the step by step instructions on how to extend the volumes without downtime.

Conclusions

Using the cloud, containers, automation or more complex orchestrators like Kubernetes, do not solve all, do not prevent mistakes from happening, and more importantly do not make the right decisions for you.

You must set up a proper architecture that includes backup, monitoring and alerting. You must set the right alerts and act on them in time.

Finally automation is cool, however the devil is in the details and typos are his day to day joy. Be careful and check what you put online, do not rush it. Validate, validate validate…

Great stateful MySQL to all.

What is dual password in MYSQL and how it works was already covered by my colleague Brian Sumpter here (https://www.percona.com/blog/using-mysql-8-dual-passwords/).

However let me do a brief recap here about it.

Dual password is the MySQL mechanism that allows you to keep two passwords active at the same time. This feature is part of a more extended set of Password management features implemented in MySQL 8 to enforce better security and secrets management, like:

• Internal Versus External Credentials Storage
• Password Expiration Policy
• Password Reuse Policy
• Password Verification-Required Policy
• Dual Password Support
• Random Password Generation
• Failed-Login Tracking and Temporary Account Locking

The most important and requested features are the password expiration and verification policy. The problem in implementing them is the complexity of replacing passwords for accounts on very large platforms, like with thousands of applications and hundreds of MySQL servers.

In fact, while for a single user it is not so complex to change his own password when requested at login, for an application using thousands of sub-services it may require some time. The problem in performing the password change is that while executing the modification some services will have the updated password while others will still use the old one. Without Dual Password a segment of nodes will receive error messages in connecting creating service disruption.

Now let us cover this blog topic.

With Dual Password it is instead possible to declare a new password keeping the old still active until the whole upgrade has been completed.

This highlight two very important aspects:

• When automating the password update, it is better to not use a password expiration policy, but base the expiration on the completion of the new password deployment.
• We need to be sure the account we are changing the password to keeps the password active until we need it, and that is correctly removed when done.

As you see I am focusing on the cases when we have automation and not the single interactive user update.

How dual password works

Let us assume we have create a user like:

create user dualtest@'192.168.4.%' identified by 'password1';
grant all on test.* to dualtest@'192.168.4.%';

This will generate an entry in MySQL mysql.user table as:

(root@localhost) [(none)]>select user,host, plugin, authentication_string, password_last_changed,User_attributes from mysql.user where user = 'dualtest'\G
*************************** 1. row ***************************
                 user: dualtest
                 host: 192.168.4.%
               plugin: mysql_native_password
authentication_string: *668425423DB5193AF921380129F465A6425216D0
password_last_changed: 2022-11-17 08:31:37
      User_attributes: NULL
1 row in set (0.00 sec)

At this point our user will be able to connect from any application located in the correct network and act on the test schema.

After some time, you as application owner,will be notified by your DBA team that the user dualtest is required to change the password in order to respect the security constraints.

At this point there are two options:

1. You have privileges  to use Dual Password (the required dynamic privilege to use dual Password is APPLICATION PASSWORD ADMIN).
2. You do not have the right privileges.

In case 2 your DBA team must perform the change for you, and then they will let you know the new password.

In case 1 you can do the operation yourself.

In the last case what you will do is:

ALTER USER 'dualtest'@'192.168.4.%' IDENTIFIED BY 'password2' RETAIN CURRENT PASSWORD;

Then check it is done properly:

select user,host, plugin, authentication_string, password_last_changed,User_attributes from mysql.user where user ='dualtest' order by 1,2\G
*************************** 1. row ***************************
                 user: dualtest
                 host: 192.168.4.%
               plugin: mysql_native_password
authentication_string: *DC52755F3C09F5923046BD42AFA76BD1D80DF2E9
password_last_changed: 2022-11-17 08:46:28
      User_attributes: {"additional_password": "*668425423DB5193AF921380129F465A6425216D0"}
1 row in set (0.00 sec)

As you can see here the OLD password has been moved to the User_attributes JSON field that is used in MYSQL8 to store several values.

At this point you can rollout safely the password change and that change can take an hour or a week, no production impact given the applications will be able to use either of them.

Once the process is complete, you can ask your DBA team to remove OLD password, or do:

ALTER USER 'dualtest'@'192.168.4.%' DISCARD OLD PASSWORD;

Then check if the password has being removed properly:

(root@localhost) [(none)]>select user,host, plugin, authentication_string, password_last_changed,User_attributes from mysql.user where user ='dualtest' order by 1,2\G
*************************** 1. row ***************************
                 user: dualtest
                 host: 192.168.4.%
               plugin: mysql_native_password
authentication_string: *DC52755F3C09F5923046BD42AFA76BD1D80DF2E9
password_last_changed: 2022-11-17 08:46:28
      User_attributes: NULL
1 row in set (0.00 sec)

If all is clean the process can be considered complete.

Of course all this should be automated and executed by code not by hand high level it should be more or less like this:

{}Input new password
- Check for additional_password in User_attributes in mysql.user
<> If no value you can proceed otherwise exit (another change is in place)
 - Read and store authentication_string for the user you need to change password
 - Change current password with: Alter user ... RETAIN CURRENT PASSWORD
 - Check for additional_password in User_attributes in mysql.user
<> If value is present and match the password stored then you can proceed otherwise exit given there is an error in Dual Password or the passwords are different
 - Run update on all application nodes, and verify new password on each application node
<> At regular interval check the number of completed changes and check the additional_password in User_attributes in mysql.user to be sure it is still there
[] When all application nodes are up to date
<> If verification is successful 100%
 - Remove OLD password with: ALTER USER ... DISCARD OLD PASSWORD;
 - Check for additional_password in User_attributes in mysql.user
<> If no value is present close with OK otherwise report Error for password not removed
() complete

Conclusion

As also Brian mentioned, those are the small things that could make the difference when in large deployments and enterprise environments. Security is a topic that very often is underestimated in small companies or start-ups, but that is wrong, security operations like password rotation are crucial for your safety.

It is nice to see that MySQL is finally adopting simple but effective steps to help DBAs to implement proper procedures without causing production impact and without the need to become too creative.

References

https://www.percona.com/blog/using-mysql-8-dual-passwords/

https://dev.mysql.com/doc/refman/8.0/en/password-management.html#dual-passwords
